Hyundai Genesis (DH): Automatic Transmission Control System / Input Speed Sensor Schematic Diagrams
| Circuit Diagram |
Specifications ? Type: Hall Effect Sensor ? Specifications Operation condition (
Inspection 1. Check signal waveform of Input speed sensor using the GDS. Specification: Refer to "Signal Wave Form" section.
Other information:
Hyundai Genesis (DH) 2013-2016 Service Manual: Heater Unit Components and Components Location
Component Location Components (1) 1. Shower duct (Left)2. Mode actuator (LH)3. Temperature control actuator (LH)4. Temperature door lever (Left)5. Mode actuator (A)6. Console temperature actuator (A)7. Console mode actuator ON/OFF8. Heater case (Left)9.
Hyundai Genesis (DH) 2013-2016 Service Manual: Auto Defogging Actuator Repair procedures
Inspection 1. Turn the ignition switch OFF. 2. Disconnect the auto defogging connector. 3. Verify that the auto defogging actuator operates to the open position when connecting 12V to terminal 3 and grounding terminal 4. Verify that the auto defogging actuator operates to the close position when connected in reverse.
