Components Location

1. Front propeller shaft
2. Transfer case
3.Front differential assembly

    Removal 1. Loosen the wheel nuts slightly. Raise the vehicle, and make sure it is securely supported. 2. Remove the front wheel and tire (A) from the front hub.
