Hyundai Genesis (DH): Front Propeller Shaft Assembly / Propeller Shaft Components and Components Location

Hyundai Genesis (DH) 2013-2016 Service Manual / Driveshaft and axle / Front Propeller Shaft Assembly / Propeller Shaft Components and Components Location

Components Location

1. Propeller shaft
2. Center bearing bracket

    Removal 1. Loosen the wheel nuts slightly. Raise the vehicle, and make sure it is securely supported. 2. Remove the front wheel and tire (A) from the front hub.

    Inspection Inspect Flexible Coupling 1. Check the front and rear flexible couplings for cracks or damage. 2. Inspect the flexible coupling centering bushing.
