| Circuit Diagram |


Components TCS:Traction Control System ESP:Electronic Stabilty Program System ACU:Airbag Control Unit CGW:Central Gate Way SCC:Smart Cruise Control LDWS:Lane Departure Warning System
Removal 1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work. 2. Remove the crash pad lower panel.
Removal 1. Disconnect the negative (-) battery terminal. 2. Remove the photo & auto light sensor. (Refer to Windshield Wiper/Washer - "Rain Sensor") Installation 1. Install the auto light sensor. 2. Connect the negative (-) battery terminal.
Removal Blind Spot Detection Warning Indicator 1. Disconnect the negative (-) battery terminal. 2. Remove the mirror (A). Installation Blind Spot Detection Warning Indicator 1. Install the outside mirror. 2. Connect the negative (-) battery terminal.
