Hyundai Genesis (DH): Automatic Transmission Control System / Output Speed Sensor Schematic Diagrams
Hyundai Genesis (DH) 2013-2016 Service Manual / Automatic Transmission System (SBC) / Automatic Transmission Control System / Output Speed Sensor Schematic Diagrams
| Circuit Diagram |
Specifications ? Type: Hall Effect Sensor ? Specifications Operation condition (
Inspection 1. Check signal waveform of output speed sensor using the GDS. Specification: Refer to "Signal Wave Form" section.
