Hyundai Genesis (DH): Automatic Transmission Control System / Damper Clutch Control Solenoid Valve Schematic Diagrams
| Circuit Diagram |
Specifications Damper Clutch Control VFS ? Control type : Normal low type Control Pressure kpa (kgf/cm?, psi)0~500.14 (0~5.1,0~72.54)Current value(mA)0~850 Internal resistance(?)4.
Inspection 1. Turn ignition switch OFF. 2. Disconnect the E Module connector. 3. Measure resistance between solenoid valve terminals. 4.
