Hyundai Genesis (DH): Cylinder Head Assembly / Cylinder Head Cover Components and Components Location
| Components |
| 1. LH cylinder head cover 2. LH cylinder head cover gasket 3. LH exhaust CVVT OCV cap | 4. RH cylinder head cover 5. RH cylinder head cover gasket 6. RH exhaust CVVT OCV cap |
Inspection Valve Clearance Inspection and Adjustment Inspect and adjust the valve clearance when the engine is cold (Engine coolant temperature : 20
Removal LH Cylinder Head Cover 1. Disconnect the battery "-" terminal from the trunk room. 2. Remove the surge tank. (Refer to Intake And Exhaust System - "Surge Tank") 3.
