Hyundai Genesis: Automatic Transmission Control System / Underdrive Brake Control Solenoid Valve(UD/B_VFS) Schematic Diagrams

Hyundai Genesis (DH) 2013-2016 Service Manual / Automatic Transmission System (SBC) / Automatic Transmission Control System / Underdrive Brake Control Solenoid Valve(UD/B_VFS) Schematic Diagrams

Circuit Diagram

Underdrive Brake Control Solenoid Valve(UD/B_VFS) Specifications
Specifications Direct control VFS[UD/C] ? Control type : Normal low type Control Pressure kpa (kgf/cm?, psi)0~1569.06 (0~16,0~227.57)Current value(mA)0~1100 Internal resistance ...

Underdrive Brake Control Solenoid Valve(UD/B_VFS) Repair procedures
Inspection 1. Turn ignition switch OFF. 2. Disconnect the E Module connector. 3. Measure resistance between solenoid valve terminals. 4. Check that the resistance is within the spec ...
