Hyundai Genesis (DH): Automatic Transmission Control System / 4&OD Clutch Control Solenoid Valve Schematic Diagrams

Hyundai Genesis (DH) 2013-2016 Service Manual / Automatic Transmission System (SBC) / Automatic Transmission Control System / 4&OD Clutch Control Solenoid Valve Schematic Diagrams

Circuit Diagram

❮4&OD Clutch Control Solenoid Valve Specifications

Specifications Direct control VFS[4&OD/C] ? Control type : Normal high type Control Pressure kpa (kgf/cm?, psi)0~1569.06 (0~16,0~227.57)Current value(mA)0~1100 Internal resistance(?)5.

4&OD Clutch Control Solenoid Valve Repair procedures❯

Inspection 1. Turn ignition switch OFF. 2. Disconnect the E Module connector. 3. Measure resistance between solenoid valve terminals. 4.
