Hyundai Genesis (DH): Automatic Transmission Control System / 8LR Brake Control Solenoid Valve Schematic Diagrams
| Circuit Diagram |
Specifications Direct control VFS[8LR/B] ? Control Type : Normal low type Control Pressure kpa (kgf/cm?, psi)0~2108.42 (0~21.5~305.80)Current value(mA)0~1100 Internal resistance(?)5.
Inspection 1. Turn ignition switch OFF. 2. Disconnect the E Module connector. 3. Measure resistance between solenoid valve terminals. 4.
